Activating TPMS

There are basically two kinds of Tire Pressure Monitoring Systems (TPMS) on Audi A3 8P cars. One kind (TPMS sensor-based) has pressure sensors in each wheel that transmit an alert to the car if pressure is outside the safe range. The other kind (TPMS wheelspeed-based) uses the ABS sensors to monitor the trends of wheel speeds with respect to each other. If one wheel loses pressure, it will have a smaller diameter and a correspondingly higher rotation speed, so a warning can be triggered.

-If you have DIS (Driver Information System) or MMI (Multi Media Interface), you don't need a button to reset TPMS (Tire Pressure Monitoring System);
-If you don't have DIS or MMI, you need a button to reset TPMS;
-Button OEM code: 8P0 927 121 A 5PR or 8P0 927 121 B 5PR
-You must check to see if your ABS controller is compatible with this mod;
-Versions claimed to work:
*1K0 907 379 BH
*1K0 907 379 AC
*1K0 907 379 AM
*1K0 907 379 BE
*1K0 907 379 K
*1K0 907 379 Q
*1K0 614 517 R

Coding

1. 17-Instruments
2. Security Access - 16
3. Password: 13861
4. Do it!

5. 17-Instruments
6. Coding - 07
7. Add +16 to the first 4 numbers
8. Do it!

9. Adaptation - 10
10. Choose Channel 37 (Special Functions II)
11. Change the second number from left from 0 to 1
12. Test, Save and Done

13. 03-ABS Brakes
14. Coding - 07
15. Long Coding Helper
16. Byte 16
17. Enable Bit 1 (Replace 0 to 1)
18. Enable Bit 2 (Replace 0 to 1)

19. Byte 17
20. Enable Bit 2 (Replace 0 to 1)
21. Exit
22. Do It!

23. 19-CAN Gateway
24. Installation List
25. 4C - Activate Tire Pressure II
26. Save coding

=ENJOY IT!=

Share this page

Please note that this is only a guide and that I take no responsibility for any damage/problems. © Copyright 2019 Audi A3 8P Retrofit - All Rights Reserved
